Technical data

Dimensions
270 x 335 x 95 mm (W x D x H)
Weight
ㆍ1,5 kg
Protection class
ㆍII, Typ BF
Measurement duration
ㆍapprox. 4 seconds (with dark alignment 15 seconds)
Guarantee
ㆍ2 years from date of purchase
Classification
ㆍClass IIa according to appendix IX of the 93/42/EC
    directive
Certification body
ㆍCE 0535
Excitation light
ㆍWavelength range : 220 - 360 nm
ㆍEnergy per flash : 0,15 (Joule max.)
ㆍAverage power : 10 (W max.)
Spectrometer
ㆍWavelength range : 200 - 1100 nm
ㆍDetector sensitivity : 86 Photons/Count
ㆍOptical resolution : ~ 0.3 nm to 10.0 nm (FWHM)
Connection cable
ㆍUSB Standard
Laptop
ㆍType : Dell Latitude 5400/Core 2 Duo or
     a similar laptop model
ㆍOperating software : Windows XP, VISTA, Windows 7
ㆍGuarantee : in case of Dell Latitude 5400: 3-Year Dell
     Business Support
